Product Description
The MikroTik CCR2004-16G-2S+ is a powerful enterprise-grade Cloud Core Router designed for Internet Service Providers (ISPs), data centers, and medium to large business networks. Combining exceptional single-core performance with high port density, it delivers fast and reliable routing, firewall, VPN, and traffic management for demanding network environments. It is powered by a quad-core 64-bit ARM Annapurna Labs Alpine v2 processor running at 1.7GHz, providing excellent performance for CPU-intensive tasks such as routing, queues, and per-connection processing.
The router features 16 Gigabit Ethernet ports and 2× 10G SFP+ ports, offering flexible connectivity for high-speed fiber uplinks and extensive wired network deployments. Two integrated Marvell switch chips ensure efficient traffic handling, while dedicated 10Gbps links between the CPU, switch chips, and SFP+ interfaces help eliminate internal bottlenecks and maximize throughput.
Equipped with 4GB DDR4 RAM and 128MB NAND storage, the CCR2004-16G-2S+ runs RouterOS v7 with a Level 6 license, supporting advanced networking features such as BGP, OSPF, MPLS, VLANs, VPNs, QoS, load balancing, traffic shaping, advanced firewalling, and network monitoring. It also includes a USB 3.0 port for external storage or additional functionality and an RJ45 serial console port for management.
Built for reliability, the router comes in a 1U rackmount chassis with dual redundant hot-swappable AC power supplies and active cooling using two intelligent fans, ensuring continuous operation in mission-critical environments. Hardware monitoring features include CPU temperature, PCB temperature, and voltage monitoring to help maintain optimal performance.
The CCR2004-16G-2S+ is an ideal solution for organizations requiring high-performance routing with multiple Gigabit connections and 10G fiber uplinks, offering an outstanding balance of speed, scalability, and value.
Key Features:
- Quad-core 64-bit ARM Cortex-A57 processor (1.7GHz)
- 4GB DDR4 RAM and 128MB NAND storage
- 16× Gigabit Ethernet ports
- 2× 10G SFP+ fiber ports
- USB 3.0 port and RJ45 serial console port
- RouterOS v7 with Level 6 license
- Dual redundant AC power supplies
- Active cooling with dual intelligent fans
- Advanced routing, firewall, VPN, MPLS, VLAN, QoS, and load balancing support
- 1U rackmount form factor
- Operating temperature: -20°C to +60°C
